P6 outdoor LED display price in Bengaluru: ₹5,000 per sq ft, installed.

PixelSpot builds P6 outdoor LED displays, P6 LED walls and LED screens for hoardings, building facades, rooftop signs and gantries, at its factory in Jalahalli, Bengaluru, and installs them with its own crew across Bengaluru and Karnataka; the LED video wall in Karnataka page covers work outside the city. P6 is the pitch for a wall read from across the road: comfortable from 6 m, at its sharpest from about 12 m, up to 4,500 nits, IP65 at the front and IP54 at the rear. It is ₹5,000 per sq ft + GST installed, the lowest outdoor rate we list, with the controller extra; the whole walls below include it.

A P6 LED wall costs about ₹5,000 per sq ft installed, excluding the controller and GST, from PixelSpot's factory in Bengaluru (Bangalore). With a Huidu controller added, that is ₹1,97,000 for an 8x4 ft wall, ₹3,48,500 for 10x6 ft and ₹5,47,500 for 12x8 ft, all + GST. The P6 we build is an outdoor SMD module: IP65 at the front, IP54 at the rear, up to 4,500 nits with auto-dimming after dark, made for a building facade, a rooftop sign, a gantry or a hoarding that people read from 6 m and further. It is the coarsest pitch we recommend for a wall that still has to carry a logo and a phone number cleanly. It is also the lowest outdoor rate we list: on our current estimates outdoor P5 (DIP) is about ₹5,150 per sq ft + GST and outdoor P4 about ₹5,300 + GST, so ask for them on the same sheet when some viewers stand closer than 6 m. The per-sq-ft rate covers the modules, receiving cards, power supplies, steel frame, cabling, transport and installation by our own crew, and excludes the controller; every wall also comes with PxlOS, 5 per cent spare modules and the 2-year pixel-to-pixel onsite warranty. GST at 18 per cent is extra, with input credit available; the HSN and GST page explains how to claim it.

P6 outdoor LED display price by size, + GST

The rows run from the smallest size on our 2026 price sheet to a 20 x 10 ft hoarding, each a complete outdoor P6 wall with frame, a Huidu controller and installation, + GST. Smaller boards are priced on survey; the configurator gives an instant figure for any size. The larger rows are where P6 belongs.

The estimate is a plain wall-mounted or fascia install, and the wall prices add a Huidu controller sized to the pixel load. The quote rises, priced for your wall, when the wall needs front-service die-cast cabinets (a facade panel flush against the building with no walkway behind it), a NovaStar-based sending and receiving system, a curved or ceiling-hung frame, or a freestanding pole, rooftop truss or gantry structure, which is quoted as a separate line after the free site survey. Municipal permission drawings, where the landlord or the BBMP asks for them, are also a separate line. The 8x4 and 10x6 ft totals in the table are arithmetic rather than advice: a P6 wall is built from whole 320 x 160 mm modules, the pixel count scales with the width, and below about 100 sq ft outdoors we usually quote P4 or P3 instead, because a small P6 surface has too few pixels to draw a logo without visible steps. P6 belongs on hoardings and facades of roughly 200 sq ft and more, read from well beyond 6 m; at our current rates P6 costs a little less per square foot than P5 and P4, so on a large wall ask for P6 and P5 priced side by side.

P6 LED display and LED screen price

A P6 LED display, a P6 LED screen and a P6 LED wall are three names for the same product: outdoor P6 modules, 6 mm between LED centres, built into one screen. The price does not change with the name. A P6 LED display or LED screen from PixelSpot is ₹5,000 per sq ft + GST, installed, with the controller extra, whether it is a board-size display or a full wall. The table above gives whole-wall prices with the controller; for any other size the configurator gives a figure, and the LED wall price in Bangalore page lists every pitch.

P6 outdoor LED display specification

Two lines on that sheet decide whether a "P6" quote from anyone is the same product as ours. The first is the module: about 53 x 27 pixels on a 320 x 160 mm board. The same board size carries P4 at 80 x 40, P5 at 64 x 32 and P8 at 40 x 20, so the module resolution cannot be fudged. The second is the scan rate: 1/8 on P6 means each LED is lit for a long slice of every cycle, which is how the module holds up to 4,500 nits in Bengaluru daylight and still dims cleanly after dark. The power consumption guide has the draw by pitch, and the brightness guide explains why a north-facing or shaded facade can run well below full brightness, and why the survey checks the angle and shading on a west-facing one.

P6 LED module vs a complete P6 LED wall

A P6 module is a 320 x 160 mm board with about 53 x 27 pixels, and online sellers price it by the piece. PixelSpot does not sell P6 modules loose. Our price is for a complete P6 wall or hoarding, installed: outdoor cabinets, the steel frame, power supplies, receiving cards, the controller, cabling, the PxlOS cloud CMS for scheduling advertisers, and the 2-year pixel-to-pixel onsite warranty, with our own crew doing the work. On a facade or a gantry the modules are the smaller part of the job; the frame, the power run and the sealing decide whether the wall is still running after its first monsoon. If you own a P6 wall from us, spare modules are part of the handover, so a damaged module is changed on site.

P6 outdoor LED screen in Bangalore: where it fits

Our configurator rates P6 for viewers from about 6 m to about 20 m and lists billboards and highway signage as what it is for. In Bangalore that is the facade read from across a four-lane road, the rooftop sign over a showroom, the stadium screen and the roadside LED hoarding. Below roughly 100 sq ft, or with pedestrians inside 6 m, a finer pitch serves better: P5 from 5 m, or the shopfront standard two steps finer; see the P4 outdoor LED display price, ₹5,100 per sq ft + GST. A very large board read only from 8 m and beyond can go to P8 or P10, both priced after a site survey.

Apply the viewing rule from the viewing distance calculator: the minimum comfortable distance in metres is roughly the pitch number, and the picture looks best from about twice that. For P6 that is 6 m minimum and about 12 m ideal. Measure from the wall to where the nearest regular viewer actually stands or drives, not to the edge of the plot. If that measurement is 6 m or more, P6 is the right pitch and paying for a finer one buys pixels nobody can resolve. If it is under 6 m, step finer. Typical P6 walls we survey in and around Bengaluru:

• Building facade on an arterial road. A screen on the front of a commercial block on Outer Ring Road, Hosur Road or Bannerghatta Road, read by people across the carriageway and by traffic slowing at the signal. Reading distance is 12 m and more, well past the P6 ideal.
• Rooftop or parapet sign on a showroom. A car or two-wheeler dealership on a highway stretch towards Tumakuru or Mysuru, with the sign lifted above the canopy and read from the approach at 12 to 30 m. See the car showroom page for the indoor counterpart.
• Mall or commercial-complex exterior above the entrance. Read from the forecourt and the drop-off lane at 6 to 12 m, with pedestrians never closer than the canopy edge.
• Temple, church or community-hall facade. A festival-season display facing the courtyard, read from the queue line and the road at 6 m and beyond. The temple page and church page cover the indoor walls; the outdoor facade at these sites is usually P6.
• College ground, sports complex or stadium screen. A scoreboard or replay screen read from the stands and the running track at 12 to 30 m, where every seat is beyond the P6 ideal distance and a surface of 200 sq ft and more makes sense. The college page has the campus context.
• Tech-park or industrial-estate gate display. A welcome and wayfinding screen at the campus entrance in Whitefield, Electronic City or Peenya, read from vehicles on the approach lane at 6 to 12 m.
• Roadside LED hoarding on a gantry or pole. The classic use: an advertising surface on a highway median or a junction, read from moving vehicles at 12 to 30 m, sold by the slot through the DOOH marketplace. How slots, loops and dayparting are sold is set out in DOOH advertising explained.

When to step finer

If pedestrians pass within 6 m of the wall, or the content includes a menu, a price list or any text smaller than a shop name, move to P5 for a nearest viewer at 5 m, or to P4, the shopfront standard, for a pavement read at 4 m. P3 at 3 m is for a fascia people read while walking up to the door. The extreme case is the Acai Theory shopfront in Indiranagar, where customers read a menu from 3 to 5 m and the answer was an outdoor P2.5, not a hoarding pitch at all.

When to step coarser

If the nearest viewer is 8 m or more away and the surface is a large hoarding, P8 reads identically from that distance, and P10 serves a wall read from 10 m and more; both are priced for your wall on request, so ask for them alongside P6 on the same quote. Between P6 and P8 the decision is usually about the smallest element in the artwork: a phone number in a footer strip survives on P6 at 12 m and may break up on P8 unless the wall is very large.

P6 vs P5 vs P8: the neighbouring pitches

P5 and P6 share a scan rate and a brightness band; the differences are the module, DIP on our P5 and SMD on our P6, and the nearest viewer, 5 m or 6 m. On a 12x8 ft wall P6 is the cheaper of the two at ₹5,47,500 against ₹5,63,500 for P5, both with a controller and + GST, and the pixel difference is invisible from 12 m. Against P8 the step is to a 1/5 scan and 457 x 304 pixels at 12x8 ft, which is a hoarding resolution: good for a brand mark and a slogan, poor for anything with a face or a line of body text. If your artwork is a photograph or a video with people in it, stay at P6. The full pitch price table lists every outdoor pitch from P3 to P10 side by side, and the pixel pitch guide covers the theory.

What a P6 wall from PixelSpot includes

• Outdoor modules and cabinets. 320 x 160 mm P6 modules, IP65 front and IP54 rear, in outdoor cabinets sized for the facade or the gantry, with a 5 per cent spare-module allowance delivered with the wall so a hit from a stone or a bird does not wait on a factory order. What the monsoon does to a sealed module, and what a facade wall adds to the power bill, is covered in the outdoor LED wall monsoon, power and GST guide.
• Steel frame. A fabricated frame for a wall-mounted or fascia install is inside the per sq ft rate. A freestanding pole, rooftop truss or gantry is designed and quoted separately after the survey, with the wind loading for the site taken into account.
• Controller: Huidu or NovaStar. The wall prices include a Huidu controller sized to the pixel load, which is what most facades and hoardings need; the per-sq-ft rate excludes it. A NovaStar sending card and receiving cards, priced on the quote, are the option for a wall that will be filmed, that carries broadcast feeds or that needs finer calibration across a large surface. The controller model is named on every PixelSpot quote so it can be compared like for like.
• PxlOS cloud CMS. Schedule advertisers by slot, change the artwork from a phone, set the auto-dimming curve for sunset and monitor the wall's health remotely; on a hoarding this is what turns the screen into an income line rather than a cost. The DOOH revenue guide for building owners covers who buys slots in Bengaluru, how to price them and which permissions to ask for first.
• Installation by our own crew. The team that assembles and burn-in tests the cabinets at Jalahalli East is the team that fits them on site. Nothing is subcontracted, in Bengaluru or elsewhere in Karnataka.
• 2-year pixel-to-pixel onsite warranty. Any dead pixel, module, power supply or card is replaced on site. After the warranty, an AMC starts from ₹150 per sq ft per year and a module swap from ₹1,800; the warranty page and repair page have the detail.
• 24-hour service response in Bengaluru. A facade that goes dark on a Friday evening is looked at within 24 hours, from a factory in the same city with P6 spares on the shelf.

Resolution and content on a P6 wall

A 12x8 ft P6 wall is 609 x 406 pixels. That is not Full HD, which is 1,920 x 1,080, and no P6 wall of shopfront size can be: the 1,200 px width at which a Full HD video shows without softening is reached only on a facade of hoarding scale. In practice this does not matter, because at 12 m the eye cannot resolve individual pixels on a P6 wall anyway, and the controller downscales a Full HD file cleanly. What matters is the artwork. Brief your designer for a P6 surface the way you would brief a printed hoarding: one message per slide, a logo that fills a large share of the height, a phone number in a single bold weight, no thin rules, no drop shadows and no body text. Photographs and video work well on P6 as long as the subject is large in the frame. Test the artwork on the wall at night as well as at noon, because auto-dimming changes how saturated colours read, and PxlOS lets you keep a day set and a night set.

Installed in Bengaluru and across Karnataka

PixelSpot has built LED walls at its own Bengaluru factory since 2022. Within Bengaluru the site survey and 3D mockup are free, delivery and installation are inside the per sq ft rate, and service response is within 24 hours. Across the rest of Karnataka, from Mysuru and Mangaluru to Hubballi, Belagavi and Kalaburagi, the P6 rate on this page is unchanged; the quote adds freight and crew travel as separate lines so you can see them. Hosur and Krishnagiri sit 40 to 90 km from the factory and are quoted as Bengaluru neighbours. We do not install outside Karnataka and its immediate Hosur and Krishnagiri fringe. See the Bengaluru page, the Karnataka districts page and the outdoor LED page for how a facade project runs. We don't rent LED walls; for a one-off event rather than a fixed facade, an event-AV company that rents screens is the right call.

How to get an exact P6 quote

1. Measure the facade or hoarding opening and the distance to where the nearest regular viewer stands or drives. That confirms P6, or tells you to step to P5 or P8.
2. Use the 60-second LED wall configurator for an instant estimate with GST, spec sheet and BOM, or WhatsApp +91 72048 08334 with the size, a photo of the wall from the road and whether there is rear access.
3. Book the free survey. We confirm the pitch on site, check the mounting surface, power and any structure needed, and send a 3D mockup of the wall on your actual building with a fixed quotation.

The LED wall price guide covers what is included in more depth, and the size pages give worked totals for 8x4 ft, 10x6 ft and 12x8 ft walls at every pitch.
