P1.8 indoor LED display price in Bengaluru: ₹8,250 per sq ft, installed.

PixelSpot builds P1.8 indoor LED displays, LED walls and LED screens with 1.86 mm modules at its own Jalahalli factory in Bengaluru, and installs them with its own team in Bengaluru and throughout Karnataka. P1.8 is the pitch we recommend for boardrooms, jewellery counters and mall entrances; if you need an LED video wall in Karnataka for that kind of room, the installed price of every standard size is on this page.

A P1.8 LED wall costs about ₹8,250 per sq ft installed, excluding the controller and GST, from PixelSpot's factory in Bengaluru (Bangalore). With a Huidu controller, that puts a 10x6 ft boardroom wall at ₹5,91,500 and an 8x4 ft counter display at ₹3,27,500, both + GST. P1.8 is the pitch PixelSpot recommends for corporate meeting rooms, jewellery counters and mall entrances, because it is the finest pitch that still sits in the mid price band: P1.5 costs about ₹12,250 per sq ft + GST, while P2.5 at about ₹6,150 per sq ft + GST shows its dot structure once a viewer is inside 2.5 m. This page gives the P1.8 price at the three common sizes, the module specification, the viewing distances that make P1.8 the right or wrong choice, and how it compares with the pitches either side of it.

P1.8 LED wall price by size

Installed estimates, excl. GST. The per-sq-ft rate of ₹8,250 covers the SMD LED modules, receiving cards, cabinets, power supplies, cabling, transport and installation by PixelSpot's own crew, and excludes the controller. Each wall total below adds a Huidu controller and is priced on the built cabinet size; every wall comes with PxlOS cloud CMS, 5 per cent spare modules and the 2-year pixel-to-pixel onsite warranty. GST at 18 per cent is added on the invoice; a registered business claims it back as input credit, which the HSN and GST page explains.

What adds to a P1.8 quote beyond ₹8,250 per sq ft

• Controller. The ₹8,250 figure is the screen alone, and the wall prices above add a Huidu controller sized to the pixel load. A NovaStar-based system, which corporate AV integrators often specify for boardrooms with multiple video sources, is priced on the quote.
• Cabinet. Rear-service steel is the base. Front-service die-cast aluminium cabinets, needed when the wall sits flush on a boardroom wall with no access behind, add to the rate.
• Frame geometry. Curved and ceiling-hung frames need more fabrication than a flat wall mount and are quoted after the free site survey.
• Brightness. Standard indoor P1.8 is up to 600 nits, dimmed for comfort in a room. A reception behind glass in direct Bengaluru sun or facing a bright street should take an outdoor-grade panel of up to 4,500 nits instead, which is a different module and is priced on the quote.

One trap when comparing P1.8 quotes: P1.8 and P2.0 sit close in price, about ₹8,250 against ₹7,750 per sq ft + GST, so one is easily passed off as the other. Insist that the module resolution is written on the quotation. A 320 x 160 mm module carrying 172 x 86 pixels is P1.86; one carrying 160 x 80 is P2.0. Without that line, a "P1.8" quote cannot be checked.

P1.8 indoor LED display price for every standard size

A P1.8 LED display, a P1.8 LED screen and a P1.8 LED wall are three names for the same product: indoor P1.8 modules, 1.8 mm between LED centres, built into one screen. The price does not change with the name. A P1.8 LED display or LED screen from PixelSpot is ₹8,250 per sq ft + GST, installed, with the controller extra, whether it is a board-size display or a full wall. The table above gives whole-wall prices with the controller; for any other size the configurator gives a figure, and the LED wall price in Bangalore page lists every pitch.

All eight standard P1.8 sizes from our price sheet, each a complete wall with a Huidu controller, installed by our crew:

A jewellery counter backdrop fits the 6x4 ft or 8x4 ft wall, a boardroom end wall fits 10x6 ft or 12x6 ft, and 16x9 ft or 20x10 ft suits an experience centre or a training hall. Smaller openings are priced on survey, and the configurator gives an instant figure.

P1.8 indoor LED display specification

The 1/43 scan is worth a sentence because it is where cheaper P1.8 panels cut corners. Each LED in a 1/43 scan module is lit for a short slice of every refresh cycle, so the driver IC has to work harder to hold full brightness, up to 600 nits, without flicker. Current-generation drivers manage 3,840 Hz at this scan; older 1,920 Hz P1.8 panels are cheaper and look identical to the eye, then show rolling bands the moment someone films the boardroom on a phone. Every PixelSpot P1.8 wall is 3,840 Hz and 14-bit grey scale, so a dark slide background stays smooth rather than stepping through visible shades.

P1.8 indoor LED screen in Bangalore: where it fits

P1.8 works from 1.8 m out to about 6 m, the range our configurator's P1.8 profile uses: 1.8 m is the closest comfortable distance, and past about 6 m the picture is no better than P2 or P2.5 at a lower price per sq ft. Closer than 1.8 m, step to P1.5. It is an indoor pitch only; a counter or display that faces the street through glass, or sits outside, needs an outdoor-grade panel with an IP65 front, an IP54 rear and up to 4,500 nits.

Apply the viewing rule: minimum comfortable distance in metres is roughly the pitch number, and the picture looks best from about twice that. For P1.8 that is comfortable from 1.8 m and ideal from around 3.5 m. Measure from the wall to where the nearest regular viewer sits or stands, not the size of the room. If that measurement lands between 1.8 m and 2.5 m, or the content is text-dense, P1.8 is the answer. The viewing distance calculator does the arithmetic for any pitch.

Bengaluru spaces where P1.8 is the right call

• Corporate boardroom, 10x6 ft. Directors around a long table sit from about 2 m at the near end to 3.5 m at the far end. At 1,638 x 983 pixels a shared spreadsheet, a video call gallery and a dashboard all read from every chair. This is the case the conference room guide covers in depth.
• Jewellery showroom counter, 8x4 ft. Customers on the far side of the counter are within 2 m of the wall behind the sales staff, and the content is gold and stone detail at high magnification. P2.5 shows dots at that distance; P1.8 does not. See the jewellery store page. The jewellery showroom LED wall guide goes into the pitch, the colour calibration for gold and where the wall should sit.
• Mall store entrance, 8x4 or 10x6 ft. Shoppers pause about 2 m from the screen and the content is fabric texture and faces. The Amukti store entrance in a Bengaluru mall is the worked example.
• Operations or NOC dashboard wall, 12x8 ft. Analysts at desks 2.5 to 3.5 m away read small fonts all day. At 1,966 x 1,310 pixels the 12x8 P1.8 exceeds Full HD, so a 1,920 x 1,080 dashboard shows without scaling. The control room LED wall sizing guide sets out the pitch, redundancy and wall-processor questions for a wall like this.
• Hospital or clinic reception, 8x4 ft. Seated patients are 2 m from a wall showing token numbers, doctor rosters and health notices, which is text at small sizes. The hospital page has the layout options.
• Car showroom configurator wall, 10x6 ft. A customer stands about 2 m from the screen while paint and trim options are cycled, and the finish detail is the point of the wall. The car showroom page explains the content workflow.
• Executive briefing centre or training room, 10x6 ft. The first row of seats is at about 2.5 m, but the content is slides with small body text, and P1.8 keeps it legible where P2.5 would soften them.

When to step finer or coarser

Step finer to P1.5 (comfortable from 1.5 m, about ₹12,250 per sq ft + GST) when people sit at a desk directly in front of the screen, which is a control room, a broadcast studio or a boardroom where the nearest chair is inside 1.8 m. Step to P1.2 (from 1.2 m, about ₹14,650 per sq ft + GST) only when the wall replaces a desktop monitor at arm's length. Step coarser to P2.0 (from 2 m, about ₹7,750 per sq ft + GST) when nobody sits inside 2 m, since the two pitches give almost the same picture. Step to P2.5 (from 2.5 m, about ₹6,150 per sq ft + GST) when the nearest regular viewer is at or beyond 2.5 m, which covers most showroom floors, restaurants, temples, wedding halls, office lobbies and event stages. Nothing coarser than P2.5 is sold by PixelSpot for indoor use.

P1.8 vs P1.5 and P2.0: the neighbouring pitches

The step from P1.8 to P1.5 costs more than the step from P2.5 to P1.8, because pixel density rises with the square of the pitch reduction and the 1/52 scan needs a higher grade of driver. On a 10x6 ft wall P1.5 is ₹9,01,000 against ₹5,91,500 for P1.8, both with a controller and + GST. Pay it when the front row is inside 1.8 m; otherwise the extra pixels are ones nobody in the room can resolve. Against P2.0 the decision is simpler: same brightness, same 3,840 Hz refresh, a slightly finer picture from P1.8 for ₹500 more per sq ft before GST. Ask for both and compare the module resolution line.

P1.8 vs P2.5: the corporate sweet spot

Nearly every office buyer in Bengaluru ends up choosing between these two. P2.5 is the most popular indoor pitch on the whole price list, and for a lobby or a showroom it is the right one. The boardroom is where it falls short.

Look at the 8x4 ft row, the size most meeting rooms take. P2.5 gives 975 pixels across, which is fine for a video, a logo loop or a menu, but a spreadsheet shared from a laptop is downscaled to fit and the cell text blurs. P1.8 gives 1,310 pixels across, above the roughly 1,200-pixel line where a Full HD source shows without visible softening, so the same 8x4 wall reads like a large monitor. P1.8 is comfortable from 1.8 m and at its best from about 3.5 m; P2.5 is comfortable from 2.5 m and at its best from 5 m, so if the nearest regular viewer is 2.5 m or further P2.5 is enough. Inside 2.5 m the P2.5 shows its dot structure and small fonts break up. The corporate office wall we built in Bengaluru was specified from the nearest seat for exactly this reason, and the guide to choosing pixel pitch walks through the same decision for any room.

P1.8 LED module vs a complete P1.8 LED wall

PixelSpot does not sell P1.8 modules on their own. Every P1.8 indoor LED display we sell leaves as a complete, installed product: 172 x 86 pixel modules in cabinets, the steel structure, receiving cards, power supplies, the controller, PxlOS, installation by our crew and the 2-year pixel-to-pixel onsite warranty. The ₹8,250 per sq ft + GST rate is that package without the controller; the size table above adds it.

The smallest complete P1.8 products we sell are the ready-sized Cinema series units described below, at 3x2, 4x2 and 5x3 ft; anything larger is built to your opening. If you were pricing modules because a wall quote looked high, check that the quote writes the module resolution down, so you can compare like with like.

What a P1.8 wall from PixelSpot includes

• Modules and cabinets built at Jalahalli East. PixelSpot has manufactured LED walls at its own Bengaluru factory since 2022. Every P1.8 wall is assembled and burn-in tested at the factory before it leaves.
• Steel frame and mounting. A wall-mounted flat frame is in the base rate. Curved, ceiling-hung and portrait frames are fabricated in-house and quoted after the free site visit.
• Controller, named on the quote. Huidu in the listed wall prices, NovaStar for AV-integrated boardrooms, priced on the quote. Receiving cards and power supplies are included either way.
• PxlOS cloud CMS. Schedule content, split the wall into zones for a dashboard beside a video feed, and push updates from any browser. The PxlOS suite page lists the modules.
• 5 per cent spare modules handed over with the wall, so a module swap is done from your own stock rather than waiting on a factory batch.
• Installation by PixelSpot's own crew. The people who assembled the wall in the factory are the people who mount, wire and calibrate it on site. Nothing is subcontracted.
• 2-year pixel-to-pixel onsite warranty and 24-hour service response in Bengaluru. AMC after the warranty is from ₹150 per sq ft per year; the warranty page sets out what is covered.
• Free site visit and 3D mockup of the wall in your actual room before you commit.

Buyers who want a P1.8 wall in a fixed, ready-sized format can also look at the Cinema series in the store: the Cinema 32 (3x2 ft, executive desks and reception counters), Cinema 42 (4x2 ft, boutique retail backdrops) and Cinema 53 (5x3 ft, boardrooms) are P1.8 indoor walls sold as complete units.

Installed in Bengaluru, delivered across Karnataka

Within Bengaluru the P1.8 rate on this page includes delivery and installation, the site survey is free and service response is within 24 hours. For the rest of Karnataka, from Mysuru and Mangaluru to Hubballi, Belagavi and Kalaburagi, the per sq ft rate is unchanged; freight and crew travel appear as separate lines on the quotation. Hosur and Krishnagiri are served as Bengaluru neighbours. PixelSpot installs in Karnataka, plus Hosur and Krishnagiri, only; a P1.8 enquiry from anywhere else is better placed with a local integrator. The Bengaluru page and the Karnataka districts page describe how a project runs in each.

How to get an exact P1.8 price

1. Measure the wall opening and the distance to the nearest regular viewer. If that distance is under 2.5 m, or the wall will show spreadsheets and dashboards, P1.8 is the pitch to quote.
2. Use the LED wall configurator for a P1.8 price in 60 seconds with GST, spec sheet and BOM, or WhatsApp +91 72048 08334 with the size and a photo of the wall.
3. Book the free site visit. We confirm the pitch, check the power circuit and rear access, and send a 3D mockup with a fixed quotation.

For the full pitch list see LED wall price by pixel pitch, and for how P1.8 fits into the wider choice the pixel pitch chooser and the LED wall price guide are the next reads.

Guides: How to choose pixel pitch · Pixel pitch, explained · Front vs rear service · Refresh rate and camera flicker
